3102 Aluminum Coil China Suppliers
3102 aluminium alloy is an alloy in the wrought aluminium-manganese family (3000 or 3xxx series). It is one of the most lightly alloyed grades in the 3000 series, with at least 97.85% aluminium by weight. Like most other aluminium-manganese alloys, 3102 is a general-purpose alloy with moderate strength, good workability, and good corrosion resistance. Being lightly alloyed, it tends on the lower strength and higher corrosion resistance side. It can be cold worked to produce tempers with a higher strength but a lower ductility
Specification of 3102 Aluminum Coil :
| Grade | 3102 |
| Temper | F |
| Coil ID | 75mm, 150mm, 200mm, 300mm, 400mm, 508mm or negotiable |
| Coil OD | Per customer’s request |
| Thickness | 6.0-10.0mm |
| Width | 200-1700mm |
| tolerance | +/-2% |
| Alloy or not | Non-alloy/pure aluminum |
| Standard | JIS, AISI, ASTM, GB, DIN, EN |
| Certification | ISO |
| Surface | Powder coated, anodized polishing, mirror finish, diamond , tread, brushed, wood grain, stucco embossed |
| Property | Anti-corrosion, heat resistant |
| Production process | Cold rolled |
| Core | Paper core |
| Coil weight | Max. 2 tons |
| Origin | China mainland |
| Payment | TT,LC |
| Package | Covered with a layer of plastic film and cardboard, packed on the wooden pallets, bound with iron belt, loaded in the containers. |
| Delivery | 15~30 days |
Chemical Composition of 3102 Aluminum Coil :
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | V | Ti |
| 3102 | ≤0.40 | ≤0.70 | ≤0.10 | 0.05-0.40 | – | – | ≤0.30 | – | ≤0.10 |
Feature of 3102 Aluminium Coil :
- High precision of dimensional tolerance
- Excellent mechanical property such as the yield strength and tensile strength, etc.
- Being highly resistant to denting
- Available in a variety of sizes and shapes with characteristics useful in a wide range of applications
Application of 3102 Aluminium Coil :
- Construction material and building material
roof panel,
ceiling
partition wall
shutters
window blind
gate
balcony
wall
road marking
street signs
road protecting plate
highway protecting plate
bridge of barrier wall
scaffold
ship plate
- Electric machine components
protective plate
protective box
capacitor box
tank of power capacitor
electrolytic
condenser
variable of battery
volume shaft
loudspeaker framework
switch plate
semiconductor radiator
magnetic disk
motor frame
fan blade
electric cooker
cooling fin
heat sink
