Aluminium Cable Foil China Suppliers
In electrical cables, aluminium foil is an essential component providing long-term protection. It also insulates against magnetic and radio frequency emissions. Used in fibre-optic cables, aluminium foil acts as a ‘tracer’ to enable testing of the integrity of cable links.
Specification of Aluminium Cable Foil:
| Alloy | 8011 |
| Temper | O |
| Thickness | 0.15~0.20mm |
| Width | 100~1220mm |
| Coil ID | 75, 150 |
Chemical Compositions of Aluminium Cable Foil:
| Alloy | Fe | Si | Cu | Mn | Mg | Cr | Zn | Ni | Ti | Other | Al | |
| Each | Total | |||||||||||
| 8011 | 0.6~1.0 | 0.50~0.9 | 0.1 | 0.2 | 0.05 | 0.05 | 0.1 | – | 0.08 | 0.05 | 0.15 | Remains |
Tensile Strength Property of Aluminium Cable Foil:
| Alloy | Temper | Thickness (mm) | Test under room temperature | ||
| Tensile Strength Rm/(N/mm2) | Elongation %(>=) | ||||
| A50mm | A50mm | ||||
| 8011 | O | >0.15～0.20 | 60～110 | – | 16 |
