3004 Aluminum Coil China Suppliers
3004 aluminium alloy is an alloy in the wrought aluminium-manganese family (3000 or 3xxx series). It is similar to the 3003 alloy, except for the addition of approximately 1% magnesium. It can be cold worked (but not, unlike some other types of aluminium alloys, heat treated) to produce tempers with a higher strength, but a lower ductility. Like most other aluminium-manganese alloys, 3003 is a general-purpose alloy with moderate strength, good workability, and good corrosion resistance.
Specification of 3004 Aluminum Coil :
| Grade | 3004 |
| Temper | all available, H1X, H2X, H3X, O, HXXX |
| Coil ID | 75mm, 150mm, 200mm, 300mm, 400mm, 508mm or negotiable |
| Coil OD | per customer’s request |
| Thickness | 0.20-8.0mm |
| Width | 8-2400mm |
| tolerance | +/-2% |
| Alloy or not | non-alloy/pure aluminum |
| Standard | JIS, AISI, ASTM, GB, DIN, EN |
| Certification | ISO |
| Surface | powder coated, anodized polishing, mirror finish, diamond , tread, brushed, wood grain, stucco embossed |
| Property | anti-corrosion, heat resistant |
| Production process | cold rolled |
| Application | storage device, decoration, pressure vessels ,etc |
| Core | paper core |
| Coil weight | 2~4 tons |
| Origin | China mainland |
| Payment | TT,LC |
| Package | Covered with a layer of plastic film and cardboard, packed on the wooden pallets, bound with iron belt, loaded in the containers. |
| Delivery | 15~30 days |
Chemical Composition of 3004 Aluminum Coil :
| Grade | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Al |
| 3004 | 0.300 | 0.700 | 0.250 | 1.0-1.5 | 0.8-1.3 | – | – | 0.250 | remains |
Feature of 3004 Aluminium Coil :
- Good corrosion resistance
- Good weldability
- Good plasticity
Application of 3004 Aluminium Coil :
- 3004 aluminium coil mainly Used for processing the component parts that need to have good formability, high solderability good resistance to corrosion , such as kitchen utensils and appliances, food and chemical products processing and storage devices, transport tank,tank of liquid products.
- 3004 aluminum coil mainly used in chemical production and storage equipment, plate processing,building materials, construction, cable pipes, sewer pipes, various parts of lamps and lanterns, cans,wave plate, building materials, color aluminum plate, electric light head.
- 3004 aluminium sheet mainly used in processing pressure vessel,pipeline,utensil,cooling fin,radiator,makeup board,copy machine roller,ship material.
