6063 Aluminum Coil China Suppliers
6063 aluminum coil in the main alloy elements for the magnesium and silicon, with moderate strength, good corrosion resistance, weldability, oxidation effect. Widely used in the requirements of a certain strength and high resistance to antibacterial corrosion of various industrial structural parts. The common state of the 6061 aluminum roll includes the O state, the T4 state, the T6 state and the T651 state. The alloy in the T651 state is stretched on the basis of the T6 state to eliminate the internal stress and thus is more suitable for forming.
Specification of 6063 Aluminum Coil :
| Grade | 6063 |
| Temper | All available, H1X, H2X, H3X, O, HXXX |
| Coil ID | 75mm, 150mm, 200mm, 300mm, 400mm, 508mm or negotiable |
| Coil OD | Per customer’s request |
| Thickness | 0.20-8.0mm |
| Width | 8-2400mm |
| tolerance | +/-2% |
| Alloy or not | Non-alloy/pure aluminum |
| Standard | JIS, AISI, ASTM, GB, DIN, EN |
| Certification | ISO |
| Surface | Powder coated, anodized polishing, mirror finish, diamond , tread, brushed, wood grain, stucco embossed |
| Property | Anti-corrosion, heat resistant |
| Production process | Cold rolled |
| Application | Storage device, decoration, pressure vessels ,etc |
| Core | Paper core |
| Coil weight | Max .2 tons |
| Origin | China mainland |
| Payment | TT,LC |
| Package | Covered with a layer of plastic film and cardboard, packed on the wooden pallets, bound with iron belt, loaded in the containers. |
| Delivery | 15~30 days |
Chemical Composition of 6063 Aluminum Coil :
| Grade | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Al |
| 6063 | 0.20-0.6 | 0.350 | 0.100 | 0.100 | 0.45-0.9 | 0.100 | – | 0.100 | remains |
Temper of 6063 Aluminum Coil :
| F | Processing state |
| H | Strain hardening state |
| O | Annealing |
| T | Heat treatment state |
| H112 | Pure state of strain hardening,adjustment has been made to degree of strain hardening and annealing |
| T4 | Solid solution treatment and natural efficiency to achieve sufficient stability condition |
| T5 | Artificial aging condition of the reentry after high temperature thermal cooling |
| T6 | Artificial aging state after solid solution treatment |
Advantages of 6063 Aluminum Coil :
1.6063 aluminum alloy for the aluminum-magnesium series of high-plastic alloy, heat treatment to strengthen the impact of high toughness
- Excellent thermoplastic, welding performance and corrosion resistance
- After processing is not deformed, the surface is very smooth, and easy to anodize and coloring
- Excellent interface characteristics, high strength, good usability, strong corrosion resistance
Applications of 6063 Aluminum Coil :
Vehicles inside and outside the wall panels, flooring, car panels and so on.
