5052 Aluminum Coil China Suppliers
Aluminum alloy 5052 contains nominally 2.5% magnesium, 0.25% chromium and has good workability, medium static strength, high fatigue strength, good weldability, and very good corrosion resistance, especially in marine atmospheres. It also has the low density and excellent thermal conductivity similar to other aluminum alloys. Alloy 5052 can be hardened by cold work and is not heat treatable to higher strength. Since the alloy spontaneously ages at room temperature immediately after cold work, all flat rolled mill products are supplied with stable properties using a stabilization treatment.
Specification of 5052 Aluminum Coil :
| Grade | 5052 |
| Temper | all available, H1X, H2X, H3X, O, HXXX |
| Coil ID | 75mm, 150mm, 200mm, 300mm, 400mm, 508mm or negotiable |
| Coil OD | per customer’s request |
| Thickness | 0.20-8.0mm |
| Width | 8-2400mm |
| tolerance | +/-2% |
| Alloy or not | Non-alloy/pure aluminum |
| Standard | JIS, AISI, ASTM, GB, DIN, EN |
| Certification | ISO |
| Surface | Powder coated, anodized polishing, mirror finish, diamond , tread, brushed, wood grain, stucco embossed |
| Property | Anti-corrosion, heat resistant |
| Production process | cold rolled |
| Application | Storage device, decoration, pressure vessels ,etc |
| Core | Paper core |
| Coil weight | Max .2 tons |
| Origin | China mainland |
| Payment | TT,LC |
| Package | Covered with a layer of plastic film and cardboard, packed on the wooden pallets, bound with iron belt, loaded in the containers. |
| Delivery | 15~30 days |
Chemical Composition of 5052 Aluminum Coil :
| Grade | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Al |
| 5052 | 0.250 | 0.400 | 0.100 | 0.100 | 2.2-2.8 | 0.15-0.35 | – | 0.100 | remains |
Feature of 5052 Aluminum Coil :
- medium tenacity
- Good corrosion resistance
- lower density
- high tensile strength
- high elongation
Application of 5052 Aluminum Coil :
This grade is used in a wide range of atmospheric environments, including food and architectural applications and in many marine environments. The magnesium content is low enough that it does not suffer from the stress corrosion cracking that can affect alloys with more than about 3.5% Mg. Alloy 5052 is also used for consumer electronics casings, notebook computers and televisions.
